Castle Link Quick Conn 010-0079-00

About this part

Quick Connect detects the presence of a Castle Link adapter on the free lead and switches the controller's signal line from the receiver to the Castle Link. The Quick Connect is recommended for the following ESCs: Surface - Sidewinder v1/2/3/SCT, SW4, Sidewinder Micro, Sidewinder Micro 2, Mamba Micro Pro, Mamba Max, Mamba Max Pro, Mamba Monster, Mamba Monster 2. Air - Phoenix ICE, Phoenix ICE HV, Thunderbird, Talon 15, 25, 35, 60, 90, Phoenix HV.

Note

• If you have a Castle ESC with dual BEC wires (Mamba XL X or Talon HV 120) or require more than 6 amps from the BEC you must use Quick Connect Duo (CSE010-0149-00).

Note

• Neither Quick Connect, nor Quick Connect Duo will work with the Field Programming Cards when used as a standalone programmer. It will ONLY work when using the Field Programming Card as a Castle Link adapter.
• Tech Tip
• Can be used with the B-Link Bluetooth adapter. The order of connection is ESC > Quick Connect > B-Link > Receiver.

Fits
