Pgs-Cle Hi-Speed Programmable Low Profile brushless Servo

About this part

Sanwa PGS-CLE Hi-Speed Programmable Low Profile brushless Servo.

Features

• FH5U: SXR (SANWA XTREME RESPONSE) Mode Compatible SSL-Compatible Programmable Servo # Compatible with CODE 10 Transmitters (M17, M12S (RS), EXZES ZZ, MT-44) Not Compatible with CODE 5 Transmitters (M12, EXZES Z, MT-4S, MT-4, MT-S) PGS Setting Gear Compatible SUPER RESPONSE (SSR) Mode Compatible HIGH RESPONSE (SHR) Mode Compatible LiPo 2 Cell Compatible High Speed Type brushless Motor Metal Gears
• Aluminum Heat Sink Black Harness Waterproof (Same as IPX4) 3 Different Preset (Base, Quick, Drift)

Specifications

• Speed: @7.4V: 0.09 sec/60 @6.0V: 0.11 sec/60 Torque: @7.4V: 177.75 oz-in (12.8 kg-cm) @6.0V: 149.98 oz-in (10.8 kg-cm)

Dimensions

• 40.5x20.5x26.5mm Weight: 50.4 g
