EC2 Device & Battery Connector

About this part

This is the Team Integy EC2 Skidproof 2 mm Connector Set

Features

• Blue plastic housing with two each 2 mm diameter male and female connectors Ideal for battery to ESC connections

You will receive

• Two EC2 Skidproof 2 mm Connectors

Requirements

• Soldering leads to connectors

Note

• The contacts install wire side into the housing. This is backwards from other brands of EC connectors.
• Order of assembly: 1. insert wire through plastic housing 2. strip and tin wire 3. pre-tin connector contact being careful to keep solder inside cup 4. solder wire into contact 5. seat contact into housing
